ELTIPLA 3
ELTIPLA 3
The ELTIPLA 3 electric desk frame allows for electric height adjustment, enabling work in both sitting and standing positions (SIT & STAND). The electric table mechanism supports a load of up to 180 kg and is one of the quietest electric mechanism on the market (43 dB). The lifting electric legs have leveling capabilities (10 mm), and the height adjusts electrically from 617 to 1267 mm. The electric table frame is designed for an angled setup with three legs and is equipped with an automatic safety brake. Drives and electronics BOSCH – SIEMENS.
| Technical details | |
| Table top | 1500 mm to 2350 mm with extension from 1200 mm to 1500 mm |
| Height range | 617–1217 mm |
| Tube dimensions | 80×60 mm, 70×50 mm, 60×40 mm |
| Colour | RAL 9006 (silver), RAL 9005 (black), RAL 9016 (white) |
| Load | up to 180 kg |
| Maximum lifting speed | 30 mm/s |
| Noise level | <43dB |
ELTIPLA 3 IMAGE GALLERY
AVAILABLE LEG OPTIONS
ELTIPLA 3
21265 | RAL 9005
31265 | RAL 9006
81265 | RAL 9016
H: 715 (617–1267) mm / W: 500 mm
Table top length: from 1500 mm to 2350 mm with extension from 1200 mm to 1500 mm
Leveling: 10 mm
FLAT
FLAT
The FLAT metal legs for table bases are made from rectangular profiles. There is a 10 mm gap between the table legs and the tabletop, creating a floating tabletop effect. Combined with connectors, the FLAT table base is designed so that the legs and tabletop align with the edge. The legs have a fixed height and feature leveling adjustment. All legs are powder-coated with no visible welds. They are packaged in sets of two in a cardboard box.
| Table Top Configuration | |
|---|---|
| Width | 600–900 mm |
| Length | 600–2000 mm |
| Thickness | 12–25 mm |
| Maximum weight | 25 kg/m2 |
| Maximum load | 150 kg/m2 |
FLAT IMAGE GALLERY
AVAILABLE LEG SIZES
FLAT 600
31489 | RAL 9006G
21489 | RAL 9005FE
Other colours by request
H: 715 mm / W: 594 mm
Table top width: 600 mm
Leveling: 10 mm
FLAT 800
31490 | RAL 9006G
21490 | RAL 9005FE
Other colours by request
H: 715 mm / W: 794 mm
Table top width: 800 mm
Leveling: 10 mm
FLAT 900
21524 | RAL 9005FE
Other colours by request
H: 715 mm / W: 894 mm
Table top width: 900 mm
Leveling: 10 mm
HAVANA
HAVANA
The HAVANA metal legs for table bases are made from square profiles. There is a 10 mm gap between the table base and the tabletop, creating a floating tabletop effect. The assembled HAVANA table base is designed so that the legs and the tabletop align with the edge. The HAVANA table legs feature leveling adjustment and can be height-adjustable (from 736 to 856 mm) with an additional plastic cap. All legs are powder-coated with no visible welds. They are packaged in sets of two in a cardboard box.
| Table Top Configuration | |
|---|---|
| Width | 600–800 mm |
| Length | 600–2000 mm |
| Thickness | 12–25 mm |
| Maximum weight | 25 kg/m2 |
| Maximum load | 150 kg/m2 |
HAVANA IMAGE GALLERY
AVAILABLE LEG SIZES
HAVANA 40/600
31428 | RAL 9006G
21428 | RAL 9005FE
Other colours by request
H: 715 mm / W: 594 mm
Table top width: 600 mm
Leveling: 10 mm
HAVANA 40/800
31429 | RAL 9006G
21429 | RAL 9005FE
Other colours by request
H: 715 mm / W: 794 mm
Table top width: 800 mm
Leveling: 10 mm
HEIGHT-ADJUSTABLE PLUG CUBO 40
30702 | RAL 7015 plastic
20702 | RAL 9005 plastic
Two plug sets are required for one leg. Using the plugs, the height of the table can be adjusted from 736 to 856 mm.
MOST
MOST
The MOST table leg is made from a rectangular profile with a cross-section. Due to its distinctive shape, the MOST metal base offers a particularly stable structure, making it suitable even for dining tables. The legs are equipped with leveling, the surface is powder-coated, and there are no visible welds. The special feature of the MOST table leg is that it allows the use of larger table tops up to 2600 mm, which is made possible by the shape of the assembled table base. They are packed in pairs in cardboard packaging.
| Table Top Configuration | |
|---|---|
| Width | 800–1000 mm |
| Length | 800–2600 mm |
| Thickness | 24 mm or more |
| Maximum weight | 30 kg/m2 |
| Maximum load | up to 150 kg/m2 |
MOST IMAGE GALLERY
AVAILABLE LEG SIZES
MOST
31270 | RAL 9006G
21270 | RAL 9005FE
Other colours by request
H: 715 mm / W: 780 mm
Table top width: min. 800 mm
Leveling: 5 mm
Length of desk bar = length of table plate – 600 mm
Example: if the table plate’s length is 1600 mm, the desk bar 1000 mm is used. The characteristic of MOST leg is the possible use of a bigger table plate, up to 2600mm, which is made possible because of the leg shape.
TILL
TILL
TILL metal legs, which, together with selected connectors, form a stable metal base, are made from rectangular iron tubes (T-leg). Fixed and height-adjustable legs (680–820 mm) are available, with the option for additional leveling using a leveling screw. The surface is powder-coated and free of visible welds. The table legs are designed for table tops with widths ranging from 600 to 800 mm. They are packed in pairs in cardboard packaging.
| Table Top Configuration | |
|---|---|
| Width | 600–1000 mm |
| Length | 800–2000 mm |
| Thickness | 24 mm or more |
| Maximum weight | 30 kg/m2 |
| Maximum load | up to 150 kg/m2 |
TILL IMAGE GALLERY
AVAILABLE LEG SIZES
TILL T 400
31272 | RAL 9006G
21272 | RAL 9005FE
Other colours by request
H: 715 mm / W: 425 mm
Table top width: 600 mm
Leveling: 10 mm
TILL T 600
31271 | RAL 9006G
21271 | RAL 9005FE
Other colours by request
H: 715 mm / W: 625 mm
Table top width: 800 mm
Leveling: 10 mm
TILL T 400 HV
31274 | RAL 9006G
Other colours by request
H: 680–820 mm / W: 425 mm
Table top width: 600 mm
Leveling: 10 mm
TILL T 600 HV
31273 | RAL 9006G
Other colours by request
H: 680–820 mm / W: 625 mm
Table top width: 800 mm
Leveling: 10 mm
TEND
TEND
TEND table legs are made from rectangular iron tubes. The column is centrally mounted in the leg (T-leg). Fixed and height-adjustable metal legs are available. The surface is powder-coated and free of visible welds. The legs are designed for table tops with widths ranging from 600 to 800 mm. They are packed in pairs in cardboard packaging.
| Table Top Configuration | |
|---|---|
| Width | 600–1000 mm |
| Length | 800–2000 mm |
| Thickness | 24 mm or more |
| Maximum weight | 30 kg/m2 |
| Maximum load | up to 150 kg/m2 |
TEND IMAGE GALLERY
AVAILABLE LEG SIZES
TEND T 400
30745 | RAL 9006G
20745 | RAL 9005FE
Other colours by request
H: 715 mm / W: 534 mm
Table top width: 600 mm
Leveling: 10 mm
TEND T 600
30744 | RAL 9006G
20744 | RAL 9005FE
Other colours by request
H: 715 mm / W: 734 mm
Table top width: 800 mm
Leveling: 10 mm
TEND T 400 HV
30986 | RAL 9006G
Other colours by request
H: 680–820 mm / W: 534 mm
Table top width: 600 mm
Leveling: 10 mm
TEND T 600 HV
30985 | RAL 9006G
Other colours by request
H: 680–820 mm / W: 734 mm
Table top width: 800 mm
Leveling: 10 mm
HQ
HQ
HQ metal legs are made from rectangular tubes. Fixed and height-adjustable legs are available. They offer a modern, stable, and elegant solution for table construction. The HQ HV metal base can be height-adjusted from 680 to 825 mm using height adjustment screws. All legs are equipped with leveling, the surface is powder-coated, and there are no visible welds. They are packed in pairs in a carton using VOGA smart packaging.
| Table Top Configuration | |
|---|---|
| Width | 600–1600 mm |
| Length | 600–2000 mm |
| Thickness | 12–25 mm |
| Maximum weight | 25 kg/m2 |
| Maximum load | up to 150 kg/m2 |
HQ IMAGE GALLERY
AVAILABLE LEG SIZES
HQ 600
31432 | RAL 9006G
21432 | RAL 9005FE
Other colours by request
H: 715 mm / W: 590 mm
Table top width: 600 mm
Leveling: 5 mm
HQ 800
31433 | RAL 9006G
21433 | RAL 9005FE
Other colours by request
H: 715 mm / W: 790 mm
Table top width: 800 mm
Leveling: 5 mm
HQ 600 HV
31434 | RAL 9006G
21434 | RAL 9005FE
Other colours by request
H: 680–825 mm / W: 590 mm
Table top width: 600 mm
Leveling: 5 mm
HQ 800 HV
31435 | RAL 9006G
21435 | RAL 9005FE
Other colours by request
H: 680–825 mm / W: 790 mm
Table top width: 800 mm
Leveling: 5 mm
HIWOOD
HIWOOD
HIWOOD table legs are made from solid oak wood in combination with metal profiles with round and rectangular cross-sections. Due to the material combination, they can be placed in any environment. The legs feature leveling adjustments. The metal parts are powder-coated, while the wooden parts are oiled. HIWOOD legs are characterized by their exceptional stability due to their design.
A special feature of the HIWOOD base is that the length of the connectors is equal to the length of the tabletop minus 400 mm.
| Table Top Configuration | |
|---|---|
| Width | 600–1600 mm |
| Length | 600–2000 mm |
| Thickness | 12–25 mm |
| Maximum weight | 25 kg/m2 |
| Maximum load | up to 150 kg/m2 |
HIWOOD IMAGE GALLERY
AVAILABLE LEG SIZES
HIWOOD FE ø50/800
31495 | RAL 9005FE, oiled oak
Other colours by request
H: 715 mm / W: 742 mm
Table top width: min. 800 mm
HIWOOD FE 70×30/800
31494 | RAL 9005FE, oiled oak
Other colours by request
H: 715 mm / W: 772 mm
Table top width: min. 800 mm
HOXO
HOXO
HOXO table legs are made from durable metal profiles with round and rectangular cross-sections. The HOXO metal base is designed to allow for a wide range of applications. The metal legs are equipped with leveling, and height adjustment (736-856 mm) is possible with additional pins. HOXO legs are powder-coated for long-lasting resistance and without visible welds. They are packed in pairs in a carton.
| Table Top Configuration | |
|---|---|
| Width | 600–1600 mm |
| Length | 600–2000 mm |
| Thickness | 12–25 mm |
| Maximum weight | 25 kg/m2 |
| Maximum load | up to 150 kg/m2 |
HOXO IMAGE GALLERY
AVAILABLE LEG SIZES
HOXO 50/600
31430 | RAL 9006G
21430 | RAL 9005FE
Other colours by request
H: 715 mm / W: 580 mm
Table top width: 600 mm
Leveling: 10 mm
HOXO 50/800
31431 | RAL 9006G
21431 | RAL 9005FE
Other colours by request
H: 715 mm / W: 780 mm
Table top width: 800 mm
Leveling: 10 mm
HEIGHT-ADJUSTABLE PLUG OXO
30704 | RAL 7015 plastic
20704 | RAL 9005 plastic
Two plug sets are required for one leg. Using the plugs, the height of the table can be adjusted from 736 to 856 mm.
HUBO
HUBO
HUBO table legs are durable and adjustable, made from metal tubes with square and rectangular cross-sections, without visible welds. The metal legs have the option of leveling and and with an additional set, the standard legs can be adjusted in height (736-856 mm). HUBO metal legs are powder-coated and packed in pairs using VOGA smart packaging. The legs are designed for easy assembly.
| Table Top Configuration | |
|---|---|
| Width | 600–1600 mm |
| Length | 600–2000 mm |
| Thickness | 12–25 mm |
| Maximum weight | 25 kg/m2 |
| Maximum load | up to 150 kg/m2 |
HUBO IMAGE GALLERY
AVAILABLE LEG SIZES
HUBO 50/600
31419 | RAL 9006G
21419 | RAL 9005FE
Other colours by request
H: 715 mm / W: 580 mm
Table top width: 600 mm
Leveling: 10 mm
HUBO 50/800
31420 | RAL 9006G
21420 | RAL 9005FE
Other colours by request
H: 715 mm / W: 780 mm
Table top width: 800 mm
Leveling: 10 mm
HEIGHT-ADJUSTABLE PLUG CUBO
30709 | RAL 7015 plastic
20709 | RAL 9005 plastic
Two pins sets are required for one leg. Using the pins, the height of the table can be adjusted from 736 to 856 mm.
